Cortizo 4600 HI IT Lift and Slide Door System
Terrace sliding window by the renowned Spanish brand
from 2636 EUR Price for the reference window 1230x1480 mm , one tilt-and-turn sash, with a double-glazed unit in a standard color. Net price for bulk orders
Production time
from 7 weeks
UwThe parameter specified applies to the reference window
0,9
UgThe parameter specified applies to the reference window
0,5
Leaf depth
78 mm
Maximum leaf size
3300 x 3300
Warranty
30/42 months
Explore Cortizo 4600 HI IT lift and slide Door System:
- Cortizo 4600 HI IT system with good thermal insulation and heat transfer coefficient Uw = 0.9
- Possibility to install triple glazing for even better thermal and acoustic tightness
- A cheaper option for your company’s customers who want large glazing, but their woodwork budget does not allow for the purchase of panoramic frameless windows Cortizo 4600 HI IT
technical specification
BrandCortizo
MaterialAluminium
Maximum leaf size3300 x 3300
Maximum leaf weight400
Maximum filling thickness55 mm
Frame depth (2 rails)160,6 mm
Leaf depth78 mm
The width of the center post50 mm
Number of panes3
UwThe parameter specified applies to the reference window0,9
UgThe parameter specified applies to the reference window0,5
Uf1,45
Warm frameYES
Warranty30/42 months
