The list of compared frameless aluminum systems:
- Schuco Panorama ASS77 vs Cortizo Cor Vision Plus
- Schuco Panorama ASS77 vs Aluprof MB-Skyline
- Schuco Panorama ASS77 vs Reynaers Hi-Finity
- Cortizo Cor Vision Plus vs Aluprof MB-Skyline
- Cortizo Cor Vision Plus vs Reynaers Hi-Finity
- Aluprof MB-Skyline vs Reynaers Hi-Finity
Would you like to know differences between certain patio doors systems? We prepared for you the comparison of aluminum sliding patio doors from Schuco, Aluprof, Cortizo and Reynaers. You can also find info and product card of other systems below.
Schuco Panorama ASS77 vs Cortizo Cor Vision Plus
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Schuco ASS 77 PD
price
17 778 USD
Width of the center post
1.46 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
6A
Wind resistance class
C3
Soundproofing
Rw 42 dB
Cortizo Cor Vision Plus
price
6637 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
881.85 lb
Maximum sash weight (automat)
1543.24 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
Rw 43 dB
Schuco Panorama ASS77 vs Aluprof MB-Skyline
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Schuco ASS 77 PD
price
17 778 USD
Width of the center post
1.46 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
6A
Wind resistance class
C3
Soundproofing
Rw 42 dB
Aluprof MB-Skyline
price
6717 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
no research
Schuco Panorama ASS77 vs Reynaers Hi-Finity
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Schuco ASS 77 PD
price
17 778 USD
Width of the center post
1.46 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
6A
Wind resistance class
C3
Soundproofing
Rw 42 dB
Reynaers Hi-Finity
price
22 312 USD
Width of the center post
1.38 in
Maximum sash weight (manual)
661.39 lb
Maximum sash weight (automat)
1653.47 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
E750
Wind resistance class
C5
Soundproofing
Rw 43 dB
Cortizo Cor Vision Plus vs Aluprof MB-Skyline
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Cortizo Cor Vision Plus
price
6637 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
881.85 lb
Maximum sash weight (automat)
1543.24 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
Rw 43 dB
Aluprof MB-Skyline
price
6717 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
no research
Cortizo Cor Vision Plus vs Reynaers Hi-Finity
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Cortizo Cor Vision Plus
price
6637 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
881.85 lb
Maximum sash weight (automat)
1543.24 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
Rw 43 dB
Reynaers Hi-Finity
price
22 312 USD
Width of the center post
1.38 in
Maximum sash weight (manual)
661.39 lb
Maximum sash weight (automat)
1653.47 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
E750
Wind resistance class
C5
Soundproofing
Rw 43 dB
Aluprof MB-Skyline vs Reynaers Hi-Finity
price
Net price for aluminum sliding patio doors with dimensions of 13 ft 1.48 in x11 ft 5.8 in. Scheme A, basic color, manual version, thermally insulated profiles, glazing unit Ug = 0.5.
Width of the center post
Width at the joint of the wings. The lower the value, the better
Maximum sash weight (manual)
Maximum weight of a single sash in the case of manual opening. The higher the value, the better
Maximum sash weight (automat)
Maximum weight of a single sash in the case of a patio doors with an automatic drive. The higher the value, the better
Maximum thickness of the glazing
Maximum thickness of the glass that can be used. The greater the value, the better (it allows to obtain better energy efficiency and use safe glazing units)
Watertightness class
It is defined by classes from 1A to 9A and the highest one, marked with the letter E, e.g. E750, E850 – the numbers are the pressure value at which the patio doors does not let water into its structure. For example, for class 9A it is 600 Pa.
Wind resistance class
Class C means that the patio doors post can bend under wind pressure by a maximum of 1/300 of its height. The number tells you how strong the wind is needed for this to happen. For C4, the wind speed is 184 km / h, for C5 as much as 205 km / h (the so-called destructive hurricane winds). In such winds a 11 ft 5.8 in high patio doors post can bend about 11.0.2 in
Soundproofing
Rw is the acoustic insulation coefficient. It is given in decibels (dB) and determines the ability of patio doors to suppress noise coming from outside the building. The higher the value, the better
Aluprof MB-Skyline
price
6717 USD
Width of the center post
0.98 in
Maximum sash weight (manual)
1102.31 lb
Maximum sash weight (automat)
1102.31 lb
Maximum thickness of the glazing
2.36 in
Watertightness class
9A
Wind resistance class
C5
Soundproofing
no research
Reynaers Hi-Finity
price
22 312 USD
Width of the center post
1.38 in
Maximum sash weight (manual)
661.39 lb
Maximum sash weight (automat)
1653.47 lb
Maximum thickness of the glazing
2.13 in
Watertightness class
E750
Wind resistance class
C5
Soundproofing
Rw 43 dB
Great job! You`ve finished reading chapter 5 of The Ultimate Guide Frameless Aluminum Sliding Patio Doors
